位数 N |
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
11 |
12 |
13 |
14 |
15 |
16 |
总长L |
49 |
62 |
75 |
88 |
101 |
114 |
127 |
140 |
153 |
166 |
179 |
192 |
205 |
218 |
231 |
|
固定孔距s |
38.4 |
51.4 |
64.4 |
77.4 |
90.4 |
103.4 |
116.4 |
129,4 |
142.4 |
155,4 |
168.4 |
101,4 |
194.4 |
207,4 |
220.4 |
TECHNICAL DATA
端子間距(Center Spase) |
13. 0mm |
壓線範圍(Wire Range) |
8mm² (Max) |
螺釘扭距(Screw Torque) |
18 Ibf. in |
額定電流(Rated Current) |
600V,40A |
衝擊耐壓(Surge Voltage) |
6000V |
絕緣材料(Insulation Body) |
PBT,UL94,V-0 |
螺釘材質(Screw Material) |
M5,STEEL |
端子材質(TerminaI Body) |
BRASS |
操作溫度(Temperature) |
-40°C~105°C |
