端子間距(Center Spase) |
7. 62mm |
壓線範圍(Wire Range) |
22-14AWG |
螺釘扭距(Screw Torque) |
7lbf. in |
韻定電流(Rated Current) |
300V, 15A |
耐電壓值(Withstanding Voltage) |
A 2500V |
絕緣材料(Insulation Body) |
PBT.UL94, V-0 |
螺釘材質(Screw Material) |
M3,STEEL |
端子材質(TerminaI Body) |
BRASS |
操作温度(Temperature) |
- 40'C 〜105°C |
