端子間距(Center Spase) |
3.50mm |
壓線範園(Wire Range) |
30-16AWG |
螺釘扭距(Screw Torque) |
2 Ibf. in |
額定電流(Rated Current) |
300V,8A |
耐電壓值(Withstanding Voltage) |
AC2500V |
絕緣材料(Insulation Body) |
Pa66,UL94,V-0 |
螺釘材質(Screw Material) |
M2,STEEL |
端子材質(Terminal Body) |
BRASS |
操作溫度(Temperature) |
-40°C~105°C |
