位数 N |
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
11 |
12 |
13 |
14 |
15 |
16 |
铝轨长L |
97 |
137 |
157 |
177 |
217 |
237 |
257 |
297 |
317 |
337 |
377 |
397 |
417 |
457 |
477 |
|
固定孔距s |
80 |
120 |
140 |
160 |
200 |
220 |
240 |
280 |
300 |
320 |
360 |
380 |
400 |
440 |
460 |
端子間距(Center Spase) |
27. 0mm |
壓線範圍(Wire Range) |
60mm²(Max) |
螺釘扭距(Screw Torque) |
40 Ibf. in |
額定電流(Rated Current) |
600V,150A |
衝擊耐壓(Surge Voltage) |
6000V |
絕緣材料(Insulation Body) |
PC,UL94,V-0 |
螺釘材質(Screw Material) |
M8,STEEL |
端子材質(TerminaI Body) |
BRASS |
操作溫度(Temperature) |
-40°C~105°C |
